Home / Products / SERVER RACK SYSTEM / KD SERIES SERVER CABINETS NINE FOLDED PROFILE

KD SERIES SERVER CABINETS NINE FOLDED PROFILE CUSTOM

Load-bearing range1500KG

KD SERIES SERVER CABINETS NINE FOLDED PROFILE SUPPLIERS

Product Standards

Basic Information

Capacity(U)
42/47
Width(mm)
600/800
Depth(mm)
600/800/1000/1100/1200

ACTUAL THICKN

Top panel2.2(mm)
Bottom panel1.7(mm)
Frame1.7(mm)

Available mounting hole shapes are round and rectangle, mounting rails' front and rear position can be accurately located and adjusted.
487mm wide space for standard equipment installation；
3 partition side panels for easy handling during dismantle and installation.
Front door and rear door can be interchanged quickly without tools, opening angle 130°, convenient for equipments installation and maintenance.
Rotary door handle, keys are universal to front and rear doors for all KD series cabinets. Plenty copper stud for convenient equipment grounding.
With cabinets connector. Complete accessories.
Provided with adjustable feet, maximum static loading is 1500kgs. Surface treatment procedure is degreasing-->pickling-->antirust and phosphorization-->water cleaning-->powder coating,
RoHS compliant.

Cabinet door style


  • A

    Perforated door with hex hole


  • B

    Two sides open door with round hole

Standard components

product details
