Basic requirements for cabinet square hole strips

1. There is a clear scale display, and the scale will not be covered after the device is placed on the rack.

2. There are no other holes except for the necessary fixed holes to increase the load-bearing strength of the square hole strips.

3. To ensure the self-force-bearing strength of the square hole strips, necessary bending treatment was carried out on them.

4. When the square hole strips are fixed to the crossbeam, the operation surface of the screw fastening should face the inner side of the cabinet, which facilitates the forward and backward adjustment of the square hole strips and the columns inside the cabinet after the cabinet is combined.

5. Reserve a patch cord space of approximately 50mm between the square hole strip on the front of the cabinet and the front door frame.

6. On both sides of the patch space between the square hole strip on the front of the cabinet and the front door, detachable air flow control baffles are set. After all the servers are installed, the cold air can only enter the servers through the server air intake plate, and after heat exchange inside the equipment, it is discharged and dissipated from the rear door of the cabinet, and will not directly enter the hot aisle through other areas. When installing the core switch, the baffles on both sides can be removed for the cable routing channels.
