Advantages and usage steps of steel power wire fixers

The steel power cable fixer is made of high-strength carbon steel and has an extremely strong load-bearing capacity, which can fix thicker cables. Meanwhile, its outer layer can be powder-coated and supports customization in various colors. It is not only elegant and stylish but also serves as an insulator to ensure electrical safety.

Installation and usage steps:

(Take a fixed 6mm diameter cable as an example)

1. The first steel power cable fixer is fixed to the cable tray with screws and nuts.

2. Place a 6mm spacer at each end of the first wire fixer. Stack the second wire fixer on top and fix it diagonally to the first wire fixer with M6*12 galvanized hex socket screws.

3. Lay a cable with a diameter of 6mm on the cloth.

4. Place a 6mm pad at each end of the tablet press to ensure that the height of the pad is the same as the diameter of the cable. Put a wire fixer on it and fix it diagonally to the lower layer with M6*12 galvanized hex socket screws.

It should be noted that during the usage process, the installation method and parameters should be adjusted according to the specific type of cable fixer and the diameter of the cable.
